Automatic Multi-Function Low Price Automatic Packaging Machine Doypack Powder Packing Machine
A single-station powder packaging machine is a machine used for packaging powder materials. During the packaging process, material transportation, weighing, and quantitative packaging are required. Here is a possible workflow:
Material transportation: The powder materials are transported to the feeding port of the packaging machine through the material conveyor. The material conveyor can use conveyor belts, screw conveyors or pneumatic conveying, etc. The appropriate conveying method can be selected according to the specific situation.
Weighing: Set up a powder weighing system in the packaging machine, usually using a load cell or load cell to measure the weight of the material. After the powder material passes through the weighing system, the weighing sensor will transmit the weight signal to the control system.
Quantitative packaging: According to the preset packaging weight, the control system will control the operation of the packaging machine based on the signal from the weighing sensor to ensure that the weight of the packaging materials meets the requirements. Usually, one-time or continuous weighing is used to achieve precise quantitative packaging results.
Packaging process: Once the packaging machine confirms that the weight of the material meets the requirements, it will automatically proceed to the next packaging operation. This may include steps such as measuring, sealing, and labeling of materials to complete the packaging process
Control system and interface: Packaging machines are usually equipped with a control system that monitors and controls the packaging process. This system can set packaging weight, packaging speed, and other parameters. It can also provide a user interface that enables operators to set up monitor and displays status and alarm information during the packaging process.
Packaging bag form: The powder packaging machine can adapt to different types of packaging bags, such as stand-up bags, four-sided sealing bags, three-sided sealing bags, etc. Choose the appropriate packaging bag form according to the characteristics of the product and market demand.
Machine Specification:
| Item | 200 | 300 | 430 |
| Bag Material | Multilayer Composite Premade Bag (e.g.: PET/PE) |
| Bag size | 100mm≤L≤200mm | 100mm≤L≤300mm | 100mm≤L≤430mm |
| 70mm≤W≤150mm | 80mm≤W≤300mm | 80mm≤W≤300mm |
| Bag Type | 3 Side Seal Bag, Stand-up Bag |
| Upgradable Bag Type | N/A | Gusset Bag, Zipper Bag, Flat Bottom Pouch (Need additional purchase of functional device) |
| Speed | 0~26bags/min | 0~15bags/min |
| Sealing Type | Plain weave | Straight grain, pitch is 1mm (Optional reticulate) |
| Sealing Width | 8mm | 10mm(5--20mm can be customized) |
| Voltage | 220V, Single-phase, 50/60HZ, 1KW | 220V, Single-phase, 50/60HZ, 1.2KW |
| Air Pressure | 0.65Mpa |
| Air Consumption | 0.2m³/min | 0.3m³/min |
| Standard machine, no additional function |
| Body Dimension | 1080*535*1010mm | 1770*600*1230mm | 1770*600*1360mm |
| Packing Dimension | 1240*670*1320mm | 1860*710*1550mm | 1860*710*1650mm |
| Export non-fumigation wooden case |
(We can provide you with exclusive packaging machine customization services according to your needs! Of course,If you need, we can also provide you with customized bag service)
